High Toughness Ortho Polyester Resin for Tent Poles
This product is an unsaturated polyester resin specifically formulated for pultrusion applications. An orthophthalic-type resin, it is designed for continuous pultrusion processes and is ideally suited for the high-speed, continuous manufacturing of products such as FRP rods.
This resin exhibits excellent wetting properties with glass fibers—resulting in minimal voids and thorough impregnation—and yields molded products characterized by high mechanical strength and exceptional toughness. Furthermore, it possesses superior weather resistance, ensuring that the finished products remain free from deformation or cracking even after prolonged use.
High Toughness Ortho Polyester Resin Overview
PLM-3017 by POLEMA is a specialized high toughness ortho polyester resin engineered for continuous pultrusion of tent poles and mosquito net poles. As a leading polyester resin supplier, we formulate this high-performance ortho polyester resin with superior weather and aging resistance to ensure finished fiberglass rods remain non-brittle under outdoor sunlight.
Core Performance Advantages
Features high strength and excellent toughness, along with exceptional resistance to high temperatures and aging. Ideal for use as outdoor tent poles, as its robust toughness ensures it remains non-brittle and highly resistant to breakage.
Product Specifications
| Item No | Chemical Category | Viscosity | Gel Time | Solid Content | Tensile Strength | Flexural Strength | Heat Deflection Temperature | Application | Feature Description |
|---|---|---|---|---|---|---|---|---|---|
| PLM-106 | Terephthalic | 400-700 | 2.5-5 | 65 | 60 | 105 | 80 | Pultruded profiles | High heat resistance |
| PLM-1002 | Orthophthalic | 600-900 | 2.5-4.6 | 61-69 | 60 | 102 | 72 | Pultruded profiles | Universal |
| PLM-3016 | Orthophthalic | 500-800 | 2.5-4.6 | 61-69 | 70 | 115 | 82 | Pultruded profiles | High modulus High strength High toughness |
| PLM-3017 | Orthophthalic | 420-800 | 2.5-4.6 | 61-69 | 70 | 115 | 78 | Tent poles mosquito net poles | High modulus High strength High toughness |
| PLM-202 | Isophthalic | 460-840 | 3.8-7.2 | 58-64 | 70 | 110 | 80 | Pultruded profiles | High Gloss High Strength |
| PLM-411 | Bisphenol A | 300-500 | 8-14 | 53-59 | 75 | 125 | 105 | Pultruded profiles | High heat resistance High strength High toughness |
Application

Tent Pole Manufacturing
FAQ
Submit your application and molding process. Our polymer engineers will provide a material selection guide and dispatch free test samples rapidly.
